Industrial Sectional Door

Industrial Sectional Door

Home home
industrialsectionaldoor

Industrial Sectional Door

Our company offers the Industrial Sectional Overhead Door which is the perfect solution for high-traffic areas that need a durable, reliable door. The sections of the door fold up flat against the ceiling when opened. The vertical opening of these doors allows for more space in front of and behind the door, making it easier to park vehicles and utilise more room inside the building. They are a great way to maximise space and keep your work area looking neat and tidy. The double-skinned steel foam-filled panels are built for heavy usage, while the aluminium framed and glazed panels provide varying degrees of high-quality vision.

They are designed to meet the specific requirements of your industrial facility. They can withstand even the most demanding workloads. With our high level of access control, you can be confident that your area is secure against unauthorised entry. To ensure that our insulated panels of the overhead door section conform to the building regulations requirements, we regularly consult with the steel suppliers' technical specifications department. This allows us to keep up-to-date with the latest changes and developments in the industry and also means that we can offer our customers a high level of durability when it comes to finishes.

Space saving

The Commercial Sectional Overhead Door is extremely versatile, able to be positioned at any angle from horizontal to vertical. This means that no matter the shape of your commercial or industrial building, you can make use of the internal space to its fullest potential. Also, the guide rails can easily adjusted to accommodate changes in the roof line, maximising efficiency and convenience.

Motorised Operations

They are made up of several panels, or sections, that hinge together and roll up to open. These can be opened manually or with a motorised drive unit. The spring mechanism on them is in position to best suit the fixing point and usage requirements. Motorised drive units are available in low, medium, and high-usage models to fit the needs of different businesses. The position of the unit can also be customised to suit the roof design and track type required.

Insulation

Insulated sectional overhead doors are the perfect choice for applications where thermal performance is paramount, such as in warehouses or industrial units where temperature-controlled storage is required. By avoiding cold bridging, they guarantee a higher thermal performance than traditional roller shutters, helping to keep your premises at a consistent temperature and preventing energy wastage.
The door panels are made of thick, rigid materials that seal tightly when closed. The joint between the door panels is sealed with a special gasket to prevent heat from escaping.

The door panels has made of thick, rigid materials that seal tightly when closed. The joint between the door panels has sealed with a special gasket to prevent heat from escaping.

Long Lasting

As your business grows, so does the importance of having a dependable and high-quality sectional door installation. Our doors will offer many years of trouble-free operation with all serviceable components easily accessed. This is in contrast to most roller doors where problems typically occur in the side channels or inside the roll barrel, requiring sectional door repair. They also have a far sturdier operation action than roller doors, thanks to having fewer moving parts. Additionally, the whole door balance is superior, meaning far less stress is placed on the electric motor (whether single or three-phase).

We’ll help you to find the perfect industrial sectional door for your needs. Call Us Now

We'll help you to find the perfect industrial sectional door for your needs.

industrial-sectional-door

They are a pre-assembled door unit that is composed of several interlocking panels. These panels are made of galvanised steel and fitted with end caps. The top and bottom panels also come with an aluminium retainer that helps to keep the top and bottom EPDM seals in place.

A variety of different locking options is available to select for this type of door. Additionally, wicket doors (doors within doors) that measure approximately 900 x 2100mm are also available. Low Threshold Profile has another feature which is equipped with a sash lock or push bar.

The outer skin is usually made from steel or aluminium and is available in any number of finishes to match the look of the building. They are finished with a powder coating that protects against weathering and corrosion. Also, the colour of the powder coating can be customised to match the building’s exterior cladding.

The internal liner skin of an industrial sectional door is typically finished in RAL 9010 white, polyester coated, stucco embossed galvanised steel as standard. This provides a durable, low-maintenance surface that is easy to clean and maintain.

Our industrial doors are manufactured under European standards EN 13241-1:2003. This ensures that our products meet the highest quality and safety requirements.

Tracks

The tracks are made from galvanised steel for superior strength and durability. They can be bolted and riveted or spot welded for a more secure connection.  Also, they are available in a variety of lift configurations, including standard lift, high lift, vertical lift, and low headroom.

Hardware

All of our hardware has galvanised for weather protection, and the doors are supplied with adjustable side hinges, intermediate hinges, nylon rollers, cable sets, bottom corner brackets, spring bumpers, and self-tapping panel fixings. This ensures that your shed will open and close smoothly, and stay securely in place in all conditions.

Springs

Our springs are individually designed for each door, ensuring a perfect fit. We only use the highest grade springs, to EN Class SH specification, for greater durability and longevity. Each one is fully keyed to the shaft, with an adjustable coupler. A spring break device is supplied as standard, for safety in case of failure.

Operators

Push-up operators are spring-loaded and work by pushing the sectional door up to the required height. Chain hoists use a chain to lift the door to the required height. Electric operators come with a starter and torque bracket. A range of safety systems are also available, including cable break and spring break devices.

Sectional doors with windows can be customised to suit the specific requirements of your industrial facility. Windows can be installed in single or multiple panels, and panels are prefinished in an extensive range of colours and materials. Door systems come with a variety of window options, including clear, tinted, or frosted glass.
There are many electric motors and controls that can used with them. These include standard electric, chain-drive, belt-drive and direct-drive motors. As commercial sectional overhead door installers, we also have various surface finishes on the panels that can be selected to match the needs of the application. The most common finishes are powder-coated steel, stainless steel, and aluminium.

Colors Available

WHITE
RAL9010

BONE WHITE
RAL9002

ANTHRACITE
RAL7018

GREY ALUMINIUM
RAL9007

MERLIN GREY
BS18B25

SILVER
RAL9006

GOOSEWING GREY
BS10A05

BLUE GREY
BS18B17

REGATTA BLUE
BS18E53

GENTIAN BLUE
RAL5010

OCEAN BLUE
BS18C39

PACIFIC BLUE
RAL5003

MOSS GREEN
RAL6005

OLIVE GREEN
RAL6003

JUNIPER GREEN
BS12B29

FOREST GREEN
RAL6002

KHAKI GREEN
BS12B21

AZTEC YELLOW
BS10E55

POPPY RED
BS04E53

VAN DYKE BROWN
RALB014

Colors Available

WHITE
RAL9010
BONE WHITE
RAL9002
ANTHRACITE
RAL7018
GREY
ALUMINIUM
RAL9007
MERLIN GREY
BS18B25
SILVER
RAL9006
GOOSEWING
GREY
BS10A05
BLUE
GREY
BS18B17
REGATTA
BLUE
BS18E53
GENTIAN
BLUE
RAL5010
OCEAN BLUE
BS18C39
PACIFIC BLUE
RAL5003
MOSS GREEN
RAL6005
OLIVE GREEN
RAL6003
JUNIPER GREEN
BS12B29
FOREST GREEN
RAL6002
KHAKI GREEN
BS12B21
AZTEC YELLOW
BS10E55
POPPY RED
BS04E53
VAN DYKE
BROWN RALB014

Our team is experienced in helping customers find the right sectional door for their industrial space.
